WLL(T) |
TEST LOAD(kN) |
I-BEAM(MM) |
A |
B |
C |
D |
E |
F |
G |
H |
J |
K |
L |
M |
N.W(KG) |
|
0.5 |
7.5 |
64-110 |
108 |
200 |
190 |
230 |
53 |
94 |
18.5 |
78 |
57 |
37 |
14 |
24 |
9.5 |
|
1 |
15.0 |
54~152 |
115 |
238 |
211 |
260 |
59 |
120 |
24 |
90 |
66 |
40 |
16 |
28 |
12 |
|
2 |
30.0 |
76~165 |
130 |
274 |
236 |
300 |
69 |
136 |
26 |
105 |
75 |
44 |
17 |
34 |
16.5 |
|
3 |
45.0 |
76~203 |
164 |
314 |
295 |
320 |
82 |
150 |
33 |
130 |
96 |
60 |
17 |
34 |
25 |
|
5 |
75.0 |
88~203 |
177 |
364 |
334 |
320 |
97 |
169 |
38 |
150 |
112 |
65 |
22 |
40 |
38 |
|
10 |
150 |
122~203 |
237 |
460 |
460 |
370 |
130 |
198 |
55 |
189 |
150 |
90 |
27 |
57 |
93 |
|
20 |
300 |
122~203 |
240 |
565 |
495 |
392 |
148 |
268 |
55 |
225 |
175 |
110 |
56 |
80 |
215 |
|
30 |
450 |
122~300 |
258 |
625 |
564 |
512 |
164 |
296 |
60 |
255 |
196 |
125 |
76 |
90 |
230 |
|
50 |
750 |
122~300 |
258 |
1255 |
564 |
512 |
164 |
296 |
60 |
255 |
196 |
125 |
76 |
90 |
610 |
